Light Duty 4X2 Diesel 16 6 Ton Wrecker Tow Truck 6T6D ISUZU

Name: Light Duty 4X2 Diesel 16 6 Ton Wrecker Tow Truck 6T6D ISUZU
Brand: SUNY
Price: 20 USD

Quality Light Duty 4X2 Diesel 16 6 Ton Wrecker Tow Truck 6T6D ISUZU for sale

Brand Name : SUNY

Model Number : SYTW6IS

Certification : CCC, ASME, BV, SGS, etc

Place of Origin : China

MOQ : 1 unit

Price : USD 20, 000 ~ 50, 000 per unit

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 1000 units per year

Delivery Time : 15 ~ 25 working days after we get the deposit

Packaging Details : Nude with waxing. Whole truck by RO - RO ship, Bulk cargo ship, SKD, CKD and so on. Upper body by Container.

Boom capacity : 6 ton

Under - lift capacity : 6 ton

Winch : 2 units, 4 ton per unit

Manual control : Manual control on both left side and right side

Electrical System : Include Wires, Sidelights, Three Work Lights, Signal Lights on Pylon

Tools : Include a pair of Fork, a pair of “ L ” Bar and a pair of Strap

Towing rating : 12 ton

Contact Now

6T6D ISUZU 6 Ton Boom Capacity 4X2 Light Duty Wrecker Tow Truck

Description:

1) Flat bed tow truck can tow 2 units truck at one time. It ’ s mainly for towing light cargo truck, mini bus and car;

2) Wrecker truck is mainly for towing medium duty and heavy duty cargo truck and bus;

3) Rotator tow truck, its boom can rotate 360 degree and suitable for all the direction towing work. It ’ s mainly for towing heavy duty cargo truck and super heavy duty trailer.

Applications:

Our high quality and competitive price 6 ton SYTW6IS rotator wrecker with wireless remote control is mainly for towing heavy duty cargo truck and super heavy duty trailer.

Competitive Advantage:

1) Wireless remote control boom, winch and under - lift is optional;

2) 12 ton towing rating;

3) Mainly made by alloy steel, high quality and competitive price.

Specifications:

6T6D ISUZU 6 Ton Boom Capacity 4X2 Light Duty Wrecker Tow Truck

Chassis model		ISUZU QL1100TPARY
upper type		6T6D Integrated
( kg ) GVW		10000
( kg ) Kerb weight		6305
( mm ) Length		7790
( mm ) Width		2260 ~ 2430
( mm ) Height		2510 ~ 2690
( mm ) Wheelbase		5200
Front wheel span / Rear wheel span ( mm )		1680 / 1650
( mm ) Front Axle / Rear Axle		1110 / 1480
( ° ) Angle of approach / Angle of mosey		21 / 12
drive type		4x2
tyre size		8 . 25 - 20
( km / h ) Max HR		110
( % ) Max GRAB		30
( m ) Max turning diameter		19
( mm ) MIN Ground Clearance		215
Engine	type	4HK1 - TC ( EURO Ⅲ )
	( kW / r / min ) power	129 / 2600
	( ml ) Displacemsnt	5193
	( N · m / r / min ) torque	500 / 1500 ～ 2000
( L ) fuel exhaustion of 100km		Diesel 16
( kg ) Rated recovery capacity		10000
underlift	( kg ) lifting capacity ( full retracted )	6000
	( kg ) Lifting capacity ( fully extended )	3500
	( mm ) Distance from tail aboard	1970
	( mm ) Stoke	720
	( ⁰ ) Tilt angle of under lift : up	11 . 5
	( ⁰) Tilt angle of under lift : down	- 3
	(⁰) Angle of loading	- 4 ～ 9
	(⁰) Angle of unloaded	- 4 ～ 93
	( mm ) under - lift fully extended max clearance from fork entry to ground	1355
BOOM	Boom stage	2
	( kg ) Max . lifting capacity	6000
	( mm ) Stoke	1540
	( mm ) Max length of boom	3130
	( mm ) Max . lifting height of hook	3155
	( ⁰) Range of elevation	3 ～ 26.5
Leg	quantity ( unit )	2
Leg	( mm) Transverse span of rear leg	1410
Winch	quantity ( unit )	2
	( kN ) Per Rated traction force	40
	( mm ) cable DIA	φ 11
	( m ) cable L	15x2
	( m / min ) Min . line speed of winch cable	3 . 23
